 THOR
TV & Satellite interconnects feature a specially stranded,
all copper design for lower signal loss and reduction in VHF
and UHF noise. Special heavy-duty double shielding protects
against outside radio frequency (RF) and electromagnetic (EM)
interference.
These interconnects feature 75 Ohm balanced
conductors in order to deliver a fuller and accurate
frequency response. A 100% aluminium foil shield rejects RF
and EM interference that causes buzz and hum. Each conductor
is surrounded by a low-loss dielectric for minimum signal
loss and accurate audio reproduction, even over long runs.
And all connectors have 24k gold contacts for maximum signal
transfer and corrosion resistance.
|
|
Unlike the inputs and outputs found on audio equipment, your video
interconnect should also have a 75-ohm impedance - as do all
Philex video interconnects. Otherwise the signal can be reflected
back and forth in the interconnect and mix with the original
signal, thus cancelling some video frequencies and thereby
losing picture detail.
THOR
Coax Interconnects maintain a 75-ohm impedance even when bent
or moved. The THOR Interconnect shield is bonded to the interconnect's
insulator, so they won't separate.
|
|
|
 |
The traditional satellite and TV connector use the
centre wire conductor as the male pin of the interconnect, which
makes a poor connection, and usually bends easily, making the
interconnect unusable. The THOR Coax Interconnects solve this
problem by using a dedicated centre pin that mates perfectly
with the socket on your receiver. |
|
COAX connectors
- Heavy mass ground shell made up of 100% brass with hard wearing
gun metal coating for more contact mass.
- Reinforced ground shell for long life.
- Precision machined to ensure the best possible signal transfer.
- Heavy-duty strain relief stands up to years of use.
- Precision 75 ohm construction.
|
|
|
| |
