Super Slim LED Modular Fittings
600mm x 600mm
LED slim panel light illuminates homogeneously over their surface, producing glare-free bright light.
It is very elegant, with a modern ultra flat design.
Easy to install and maintain.
Ideal for commercial applications
such as office buildings, supermarkets, shopping malls, conference halls and hotels.
External Plug-In Driver - Required for each Panel - See Below
All of our LED panels use external driver/power supply - (Plug and Play) making installation easier and faster.
- Fittings can be installed at the last minute and can be removed or moved without re-wiring, it allows you to change the driver (dimming or non dimming without having to buy a new fitting)
- LEDlite 600mm x 600mm LED Panel are designed to be fully recessed into a tile grid ceiling system
- LEDlite 50w panel produces 50% more light at desk height when compared to a conventional 4 x 20w fitting**
- Replace and reduce the quantity of existing modular fittings
- Use with Occupancy PIR Switches for more savings.
- Even and improved light distribution.
- Instant start, no flicking, no humming.
- Cool running with no thermal effect
- Longer life, no maintenance
- No RF interference.
- Emergency and Dimmable Options
- Ideal for corridors, office and ancillary areas
- 50% Energy Saving (compared with 4 x 20W switch start)**
- Each panel equivalent to 6 x 18w T8 Tubes Fluorescent
- Sealed Fitting - Insect Resistant
- Fitting: 595mm x 595mm x 40mm
- Driver: - 170 x 50 x 35mm
- Frame Colour: White
Cost Savings EXAMPLE
Based on 15p per kW/hr - 10 hours use per day
Office Size - 6Mtr x 7Mtr x 2.4Mtr
Calculated with Relux lighting design software
- 6 x LT SP50CW Panels c/w driver @ £64.45 = £386.70
After energy saving tax allowance @20% Nett* £306.36
1st year electricity cost £147.42
First Year Cost £453.56
- 9 x 4x18w Fluorescent Modular's @ £22.00 = £198.00
36 x 18w tubes @ £1.85 £66.60
1st year electricity cost £388.21
First Year Cost £652.81
- 2nd and subsequent years
Electricity Savings £240.79
- More Cost Savings
36 Fluorescent tubes changed every 2 years = £66.60
Labour if required (approx) = £36.00
- Improved lighting by using 6 x LT SP50CW & saving £240
6 x LT SP50CW LED fittings - Lux @ desk Height = 406 lux
9 x 4x18w Switch Start Fittings - Lux @ desk Height = 380 lux
- *Customers should check with your own accountants to confirm allowance %
As above with 24hr a day use - Call Centers - would have yearly electricity savings of £577.00
- Guarantee - 5 Years**
**General Office Use 12hrs a day
