80mm x 45mm 32mm deep

115 x 95 x 35mm.
Weatherproof Splitter
The OPTIMA™ SP2 passive Splitter/Combiner is a high quality yet cost effective fully screened module using the latest SMD components.

This model has been designed for professional or contract terrestrial installation, for use in an external environment with high quality mast or bulkhead weatherproof housing.
  • Professional standard
  • 2-way Splitter/Combiner
  • High quality fully screened metal housing
  • Removable electronics module for easy connection
  • Mast or bulkhead mount weatherproof housing with positive slide down cover
  • Bi-directional DC pass available from input to output 1
  • No of inputs 1
  • No of outputs 2
  • Frequency range 85 – 862MHz
  • Insertion loss <4.8dB
  • Isolation / Output to Output >20dB
  • Connectors F – Female type
  • DC Pass @ 500mA (Max) Bi-directional from Input to Output 1 only.
Product Code
Price (ex VAT)
Price (inc VAT)
product photo
MX 302

Weatherproof Tv Splitter
