Labgear
13dB Gain Two Way Masthead UHF Pre-Amp
13dB Gain Two Way Masthead UHF Pre-Amp
- 1 input and 2 outputs with filtering to prevent interference from LTE800 4G transmitters
- Lifts signal to feed an extra point and overcome loss in cables
- Operating frequency 470-790MHz
- Easy to install, nothing to adjust
- Gain per port 9dB
- Noise figure <1.7dB
- Fully screened module tilts-out to make cable connection simpler
- Heavy duty metal mast clamp for sturdy fitting
- New weatherproof housing with foam seal
- Dimensions 140 x 95 x 55mm
- Frequency range: 470 - 782MHz
- Gain: 10dB
- Noise figure: 2dB
- Isolation: 15dB
- RED & EMC compliant
- Power input required 12VDC 30 - 35mA
Technical:Installation 914kb pdf |
Order Code
Description
Price (ex VAT)
Price (inc VAT)
Quantity
MX LMA209F
13dB Gain Two Way Masthead UHF Pre-Amp
EACH |
3+ |
|---|---|
£8.30 |
£7.80 |
EACH |
3+ |
|---|---|
£9.96 |
£9.36 |
Accessories
Order Code
Description
Price (ex VAT)
Price (inc VAT)
Quantity
MX SATP
Satellite Plug F Type
EACH |
10+ |
|---|---|
£0.35 |
£0.30 |
EACH |
10+ |
|---|---|
£0.42 |
£0.36 |
MX 200
Mast Head 12v Supply Unit
EACH |
|---|
£6.25 |
EACH |
|---|
£7.50 |
