OSP1-60 1pr 18AWG Overall Foil Screen 600V Grey LSZH (8760) - 100m
Product Code: CA 8760
5056631505754
SFX/OSP1-60-LSZH-GRY-100
Loading …
Securiflex
OSP1-60 1pr 18AWG Overall Foil Screen 600V Grey LSZH (100m)
Belden 8760 Equivalent Cable
OSP1-60 1pr 18AWG Overall Foil Screen 600V Grey LSZH (100m)
Belden 8760 Equivalent Cable
Finish:
Grey.
OSP1-60 1pr 18AWG Overall Foil Screen 600V Grey LSZH (8760) CPR:Eca
General purpose foil screened single pair cables with a small outer diameter,
frequently used in audio, data and instrumentation applications.
Polyethylene insulation results in lower signal loss than standard PVC insulation.
Grey.
OSP1-60 1pr 18AWG Overall Foil Screen 600V Grey LSZH (8760) CPR:Eca
General purpose foil screened single pair cables with a small outer diameter,
frequently used in audio, data and instrumentation applications.
Polyethylene insulation results in lower signal loss than standard PVC insulation.
- Conductor: Tinned Copper.
- Conductor Diameter mm: 0.24 ±0.008 x 16.
- Stranded Diameter (mm): 1.15.
- Insulation: HDPE.
- Insulation Thickness (mm): 0.450.
- Insulation Diameter (mm): 2.05 ±0.10.
- Insulation Colours: Black, Clear.
- Sheath Printing: OSP1-60 2x18AWG 600V Overall Screened LSF RoHS2 (PO) (m).
- Max Conductor DC resistance @ 20°C: <25.00O/km
- Al-PET Shield: >=115%.
- Drain Wire: Conductor - Tinned Copper at 0.29 ±0.008 x 7 Diameter.
- Jacket: LSZH.
- Jacket Thickness: 0.70mm.
- Overall Diameter: 5.50 ±0.20.
- Jacket Colour: Grey RAL 7042.
- Reaction to Fire: ECA.
- Insulation Resistance @20°C: >200MO/km
- Rated: Temperature: 70°C.
- Rated Voltage: 600V.
Technical:CA8760 - pdf |
|
Product Code
Description
|
Price (ex VAT)
Price (inc VAT)
Metres
|
|---|---|
|
CA 8760
OSP1-60 1pr 18AWG Overall Foil Screen 600V Grey LSZH (8760) - 100m |
