40 Amp 30mA SP+N RCBO - Contactum 6kA (Type A) B Curve - 1 Module
Product Code: CP BR06401AB
5056199098521
CCPBR06401AB
Loading …
Contactum
40A 6kA Type A SP+N Compact RCBO
B Curve
40A 6kA Type A SP+N Compact RCBO
B Curve
Regulation 722.531.3 of BS7671:2018+A2:2022 (the wiring regulations) requires that the RCDs used to
protect EV car chargers shall disconnect all live conductors. The neutral is considered a live conductor
and therefore must also disconnect in the event of a fault.
Contactum's single module SP+ N 30mA RCBO is designed to assist contractors to comply with this requirement .
This device is of a compact design and slots seamlessly into the Defender 2 Consumer Units.
It incorporates Type A RCD protection with a current rating of 40A in B overcurrent curve.
protect EV car chargers shall disconnect all live conductors. The neutral is considered a live conductor
and therefore must also disconnect in the event of a fault.
Contactum's single module SP+ N 30mA RCBO is designed to assist contractors to comply with this requirement .
This device is of a compact design and slots seamlessly into the Defender 2 Consumer Units.
It incorporates Type A RCD protection with a current rating of 40A in B overcurrent curve.
- Rated voltage: 220-250V
- Rated current: 40A
- Rated kA: 6
- Frequency: 50-60Hz
- Ambient operating temperature: -5 to 40°C
(24 hour average not exceeding 25°C) - Wiring system: 2 pole
- Min. switch contact gap: 4mm
- Width in number of modular spacings: 1
- Nature of supply: AC
- Rated fault current: 30mA
- Release characteristic: B
- Mounting method: DIN Rail
- Associated standards: BS EN 61009
Technical:CPBR06401AB Datasheet - 1.38mb pdf |
|
Product Code
Description
|
Price (ex VAT)
Price (inc VAT)
Quantity
|
|---|---|
|
CP BR06401AB
40 Amp 30mA SP+N RCBO - Contactum 6kA (Type A) B Curve - 1 Module |
