12 Way Metal Dual Split Consumer Unit - Flush - Discontinued

Please try CP Dual RCD Consumer Units for alternative products.

12 Way Metal Dual Split Consumer Unit - Flush0CPDS128MF

Supplied less MCB's

Standards:
Consumer unit - BS EN 60439-3
Isolator - BS EN 60947-3 AC22
RCD - BS EN 61008 Type A

Terminal capacities:
100A Main switch - 35/50mm²
80A RCD - 35mm²
Neutral / Earth bars 16mm²

Dimensions (mm)
H-240 W-405 D-90 + 26 (door)
Contactum "CP" Range
12 Way Metal Dual Split Consumer Unit - FLUSH
Maximum Combinations - 12 ways
100A Isolator (4 ways), 80A 30mA RCD (6 ways) & 80A 30mA RCD (6 ways)

Uses a flexible configuration to provide optimal combinations of RCD’s, MCB’s and RCBO’s
Direct fed section for individual MCB’s or RCBO’s
Two RCD sections allow division of circuits to minimise nuisance tripping
Other configurations can be supplied to order

Supplied less MCB's
  • Designed and manufactured in London
  • Tested to BS EN 60439-3 in a UKAS accredited laboratory
  • Generous cabling space
  • Secure 3 point fixing
  • Coloured MCB dolly's for easy identification
  • All devices lockable off
  • Full range of command and control devices
  • Full customer design service available
  • Knockouts -
    Top & bottom: 2 x 32mm, 2 x 25mm, 5 x 20mm,
    Sides: 1 x 32mm
    Back:, 8 x Rectangle 20mm x 50mm

Technical:

CP Range Catalogue - 450kb pdf

Order Code
Description
Price (ex VAT)
Price (inc VAT)
Quantity
product photo

CP DS128MF

12 Way Metal Dual Split Consumer Unit - Flush Special Offer

EA

£56.00

EA

£67.20

Discontinued
