IS-FS300 Wireless Sensor - White - Discontinued

IS-FS300 Wireless Sensor - White4007841705213705213

Loading …

Dimensions (h x w x d)
85 x 60 x 95 mm

9v battery not included
Steinel IS-FS300
Wireless Sensor - White - IP 54
Wireless freedom is now even more reliable and flexible:
The new STEINEL Impulser series combines cutting-edge sensor technology,
intelligent processor control and reliable 868.3 MHz wireless communication
to create an innovative solution for exacting surveillance applications.

The system's hi-tech components can be combined or grouped in any way
to provide the perfect solution for your very own particular needs.

The battery-operated IS-FS 300 infrared sensor is the ideal solution
for integrating areas in the system that are not served by mains power.
  • Quick and easy to install without laying cables
  • Sophisticated combination options for transmitting and receiving
  • Transmitters and receivers can be configured in any chosen way
  • Reliable wireless communication at 868.3 MHz
  • Sensors, outdoor and indoor lights can be interconnected in any way you choose
  • Safety and security
  • Light switches on automatically to deter uninvited guests
  • Guards and lights up areas in the home, businesses, industry and public places.
  • Convenience
  • Lights conveniently switched ”ON” by remote control
  • State-of-the-art 868.3-MHz wireless technology
  • Operating voltage / mains connection
    9 V block battery* (alkaline) (min. life 12 months.)**
    ** depending on triggering frequency (frequency of motion detection)
  • Detection reach - 12 m max., electrically stabilised
  • Sensor system
    10 detection levels,
    720 switching zones
  • Angle of coverage
    300° horizontally,
    180° vertically
  • Sensor turning range - ± 80°
  • Transmitter range
    Up to 100 m with uninterrupted line of vision dia. or 30 m indoors
  • Time setting - 1 min. - 15 min.
  • Twilight setting - 2 – 2000 lux
  • Enclosure - IP 54
  • Operating frequency - 863,3 MHz (ISM-Band)
  • Transmitter power - less than 1000 µW
  • Programming
    5 way DIP switch
    32 possible addresses per channel
  • Number of receivers - Any


IP Rating Chart Installation / Instructions - FS300 Steinel Wireless
  Order Code Description Price (ex VAT) Price (inc VAT) Quantity
product photo ST FS300W IS-FS300 Wireless Sensor - White
