15 Way Hi Integrity Dual RCD + 100A Main Switch Metal Consumer Unit5013601079721NHRS15SSLMHI
Loading …
Supplied less MCB's
Dimensions (mm)
Height: - 230mm
Width: - 438mm
Depth: - 121mm Inc Lid
15 Way Hi Integrity Dual 80A RCD + 100A Main Switch
Metal Consumer Unit
Metal Consumer Unit
and circuits with individual RCBO or MCB protection
Almost unlimited combinations
1 x 100 Amp DP Main switch controls the entire board and allows for up to 5 x RCBO's or MCB's circuits
2 x 80 Amp 30mA RCD allowing form RCD circuits to be split around a building
Max No of MCB's or RCBO's = 15
- Allows 100% RCD Protection
- Option for High Integrity with Individual RCBOs
- Dual 80Amp 30mA RCD Protection
- Allows for RCD Exemptions on MCBs
- Second RCD for 2nd Group of Circuits
- Main Switch controls all circuits
Technical:17th Edition Cosumer Units |
| Order Code | Description | Price (ex VAT) | Price (inc VAT) | Quantity | |
|---|---|---|---|---|---|
|
WY NHRS15SSLMHI | 15 Way Hi Integrity Dual RCD + 100A Main Switch Metal Consumer Unit |
Wylex for MCBs NH & NS Boards
Loading …
NSB mcb's designs are subject to change
MCB's may differ slightly on new purchases and from existing mcb's
but are all interchangeable
MCB's may differ slightly on new purchases and from existing mcb's
but are all interchangeable
Wylex NHXB - MCB's ( Type B )
General Domestic Consumer Unit use
Wylex NSB MCB's detect overcurrents due to both overload and fault currents.
The MCB will operate and interrupt the supply to prevent damage to the installation.
| See product for Accessories |
Technical:MCB Selection Data Sheets |
| Order Code | Description | Price (ex VAT) | Price (inc VAT) | Quantity | |||||
|---|---|---|---|---|---|---|---|---|---|
 |
WY NHXB06 | 6 Amp Wylex MCB - B Type |
|
|
|||||
 |
WY NHXB10 | 10 Amp Wylex MCB - B Type |
|
|
|||||
 |
WY NHXB16 | 16 Amp Wylex MCB - B Type |
|
|
|||||
 |
WY NHXB20 | 20 Amp Wylex MCB - B Type |
|
|
|||||
 |
WY NHXB32 | 32 Amp Wylex MCB - B Type |
|
|
|||||
 |
WY NHXB40 | 40 Amp Wylex MCB - B Type |
|
|
|||||
 |
WY NHXB50 | 50 Amp Wylex MCB - B Type |
|
|
|||||
 |
BK GCD | Circuit Detail Labels - pack of 25 - NICEIC |
|
|
|||||
 |
CG PL | Padlock and Locking Device for MCB's and RCBO's |
|
|
Wylex for MCBs NH & NS Boards
Loading …
Wylex NHXC - MCB's ( Type C )
| See product for Accessories |
Technical:MCB Selection Data Sheets |
| Order Code | Description | Price (ex VAT) | Price (inc VAT) | Quantity | |||||
|---|---|---|---|---|---|---|---|---|---|
 |
WY NHXC06 | 6 Amp Wylex MCB - C Curve |
|
|
|||||
 |
WY NHXC10 | 10 Amp Wylex MCB - C Curve |
|
|
|||||
 |
WY NHXC16 | 16 Amp Wylex MCB - C Curve |
|
|
|||||
 |
WY NHXC20 | 20 Amp Wylex MCB - C Curve |
|
|
|||||
 |
WY NHXC32 | 32 Amp Wylex MCB - C Curve |
|
|
|||||
 |
WY NHXC40 | 40 Amp Wylex MCB - C Curve |
|
|
|||||
 |
WY NHXC50 | 50 Amp Wylex MCB - C Curve |
|
|
Wylex 30mA Single Module SP RCBO (Type B)
Loading …
Wylex 30mA Single Module SP RCBO
(Type B)
(Type B)
An RCBO is a combination of an MCB and RCD
This enables both overcurrent protection and earth fault current protection by a single unit.
They are suitable also for installation in Wylex Consumer and in two or four module enclosures.
The current carrying capacity of the cable should always exceed the current rating of the MCB.
| See product for Accessories |
| Order Code | Description | Price (ex VAT) | Price (inc VAT) | Quantity | |||||
|---|---|---|---|---|---|---|---|---|---|
 |
WY NHXSBS6B | 6 Amp 30mA RCBO SP B Type - Wylex |
|
|
|||||
 |
WY NHXSBS10B | 10 Amp 30mA RCBO SP B Type - Wylex |
|
|
|||||
 |
WY NHXSBS16B | 16 Amp 30mA RCBO SP B Type - Wylex |
|
|
|||||
 |
WY NHXSBS20B | 20 Amp 30mA RCBO SP B Type - Wylex |
|
|
|||||
 |
WY NHXSBS32B | 32 Amp 30mA RCBO SP B Type - Wylex |
|
|
|||||
 |
WY NHXSBS40B | 40 Amp 30mA RCBO SP B Type - Wylex |
|
|
|||||
 |
WY NHXSBS50B | 50 Amp 30mA RCBO SP B Type - Wylex |
|
|
|||||
|
CG PL | Padlock and Locking Device for MCB's and RCBO's |
|
|
Wylex 30mA Single Module SP RCBO (Type C)
Loading …
Wylex 30mA Single Module SP RCBO
(Type C)
(Type C)
An RCBO is a combination of an MCB and RCD
This enables both overcurrent protection and earth fault current protection by a single unit.
They are suitable also for installation in Wylex Consumer and in two or four module enclosures.
The current carrying capacity of the cable should always exceed the current rating of the MCB.
| See product for Accessories |
| Order Code | Description | Price (ex VAT) | Price (inc VAT) | Quantity | |||||
|---|---|---|---|---|---|---|---|---|---|
 |
WY NHXSBS6C | 6 Amp 30mA RCBO SP C Type - Wylex |
|
|
|||||
 |
WY NHXSBS10C | 10 Amp 30mA RCBO SP C Type - Wylex |
|
|
|||||
 |
WY NHXSBS16C | 16 Amp 30mA RCBO SP C Type - Wylex |
|
|
|||||
 |
WY NHXSBS20C | 20 Amp 30mA RCBO SP C Type - Wylex |
|
|
|||||
 |
WY NHXSBS32C | 32 Amp 30mA RCBO SP C Type - Wylex |
|
|
|||||
 |
WY NHXSBS40C | 40 Amp 30mA RCBO SP C Type - Wylex |
|
|
|||||
|
WY NHXSBS50C | 50 Amp 30mA RCBO SP C Type - Wylex |
|
|
|||||
|
CG PL | Padlock and Locking Device for MCB's and RCBO's |
|
|
Accessories and Blanks
| Order Code | Description | Price (ex VAT) | Price (inc VAT) | Quantity | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
WY NH00 | Blank for NH / NS Consumer Units |
|
|
|||||||||
 |
WY NH17FL | Flush Lid for NHRS17SLM & NHRS15SSLMHI | |||||||||||
 |
WY NHB1PP | Blank for Wylex NH Consumer Units - Din Rail Mounted |
|
|
|||||||||
 |
WD 328PW | DeWalt Wall-Dog 32mm x 8mm Pan Head - White |
|
|
|||||||||
 |
WD 328PC | DeWalt Wall-Dog 32mm x 8mm Pan Head - Chrome |
|
|
