Solar Straight Connector Type 4
Loading …
Solar Straight Connector Type 4
Male & Female
Male & Female
interconnection or added to solar modules with existing straight Type 4 connectors for extended distances.
Greatly speeds up installation of solar array.
With excellent ageing resistance and UV endurance, it can be used in harsh environments.
The cable connects by means of a rivet and lock.
It does not need extra instruments for the removal of plugs and removal will not cause any harm to plugs.
Male connectors are fully labelled "Do not disconnect under load"
|
Product Code
Description
|
Price (ex VAT)
Price (inc VAT)
Quantity
|
|---|---|
Contactum 4 Pole DC Isolator - IP66
Loading …
Contactum
4 Pole DC Isolator - IP66
4 Pole DC Isolator - IP66
In photovoltaic applications, DC isolators are used to manually disconnect solar panels
for maintenance, installation or repair.
The panel needs to be isolated from the AC side, so a manually operated isolation switch
is placed between the panel and the inverter input. This type of switch is called a PV DC isolator
because it provides DC isolation between the photovoltaic panel and the rest of the system.
for maintenance, installation or repair.
The panel needs to be isolated from the AC side, so a manually operated isolation switch
is placed between the panel and the inverter input. This type of switch is called a PV DC isolator
because it provides DC isolation between the photovoltaic panel and the rest of the system.
- Function: isolation, control
- Number of poles: 4
- Rated voltage (Ue): 1200V DC
- Rated current (In): 16A or 32A
- Rated insulation voltage (Ui): 1200V DC
- Rated impulse voltage: (Uimp): 8kV
- Mechanical life: 20000 operations
- Screw torque (Nm): 1.2Nm
- Cable size (mm²): 4-16mm²
- Protection level: IP66
- Ambient operating temperature: -25°C to 85°C
- Standards: IEC60947-3, DC-21B
Technical:DC Isolators Datasheet - 660kb pdf |
|
Product Code
Description
|
Price (ex VAT)
Price (inc VAT)
Quantity
|
|---|---|
25A 4 Pole DC Rotary Isolator - IP66
Loading …
25A 4 Pole DC Rotary Isolator - IP66
Applications:
Photovoltaic - Isolators
Inverter Applications
DC Solar Pumps
Photovoltaic - Isolators
Inverter Applications
DC Solar Pumps
- Flexible installation options (multiple configurations)
- Padlockable in the OFF position for added security (up to 3 padlocks)
- 4 x M20 cable entries
- Robust polycarbonate enclosure
- UV resistant
- Switch rated at 1500V DC
- Excellent switching and high short circuit capacity
- Wiping contacts
Technical:EULBDC254P Datasheet - 1.55mb pdf |
|
Product Code
Description
|
Price (ex VAT)
Price (inc VAT)
Quantity
|
|---|---|
BG 100A MID Meter - Single Module
Loading …
BG
100A MID Meter - Single Module
100A MID Meter - Single Module
This MID approved meter measures both imported & exported energy. It is ideal for renewable PV applications, EV charger installations, and the monitoring of dedicated power to circuits. The inbuilt Modbus RS485 data connection allows for network integration by allowing the inbuilt registers to display data onto a computer or device.
A compact module with a width of 18mm size which is DIN rail mountable, designed for installation within BG consumer units.
Accepting up to 25mm² cable conductors of the monitoring circuit, this meter does not require the addition of CT clamps for monitoring, only a single neutral connection is required for meter operation.
A compact module with a width of 18mm size which is DIN rail mountable, designed for installation within BG consumer units.
Accepting up to 25mm² cable conductors of the monitoring circuit, this meter does not require the addition of CT clamps for monitoring, only a single neutral connection is required for meter operation.
- 100A rated
- DIN rail mounting
- 18mm single module installation
- MID approved
- Import and export monitoring
- Inline connection
- RS485 Modbus connection
- Backlit display screen
- Fixed or product scrolling display
-
Single touch button operation for setup
and menu navigation - Meter functions:
Real time active energy (kWh)
Reactive energy (kVArh)
Voltage (V)
Current (A)
Active power (W)
Reactive power (Var)
Power factor (PF)
Supply frequency (Hz)
Technical:BGMID100A Datasheet - 160kb pdf |
|
Product Code
Description
|
Price (ex VAT)
Price (inc VAT)
Quantity
|
|---|---|
FuseBox 63A 2 Pole 30mA Type B RCD
Loading …
FuseBox
63A 2 Pole 30mA Type B RCD
63A 2 Pole 30mA Type B RCD
63A 2 Pole 30mA Type B RCD for FuseBox consumer units.
Suitable for:
- EV Electric vehicle charging
(DC fault current greater than 6mA)
- PV photovoltaic systems
- Inverters
- Uninterruptible power supplies (UPS)
Suitable for:
- EV Electric vehicle charging
(DC fault current greater than 6mA)
- PV photovoltaic systems
- Inverters
- Uninterruptible power supplies (UPS)
- 63A rated
- 2 pole
- 30mA rated fault current
- Type B
- Max. terminal capacity: 35mm²
Technical:FBRTB630302M Datasheet - 300kb pdf |
|
