EHC Under Tile / Under floor heating Kits

Loading …

EHC Under Tile Heating Kits
EHC heating cable are designed to heat stone or ceramic floors
especially suitable for floors in bathrooms, kitchens, conservatories, living rooms, nurseries, etc
.

Plus the biggest selling feature for the new EHC kits is the size of the cable
Being only 4mm
  • Application
    EHC heating cables are designed to heat stone or ceramic floors. They can be installed in a screed or directly into the tile adhesive.
  • The cables are ideally suited to irregular shaped areas.
  • In poorly insulated properties supplementary heating may be required.
  • Features
    An EHC heating cables are supplied with high adhesive tape to hold the cable to the sub-floor.
  • The 4mm diameter cable keeps the increase in floor height to a minimum.
  • 3m cold lead.
  • As the cable is not fixed to a web it is easy to cope with irregular features such as bay windows and kitchen islands
  • Selection
    Firstly calculate the area of floor to be heated. This will be the total floor area minus the area occupied by fixtures such as cupboards, sinks, baths etc.
  • You will see that each EHC heating cables has a stated minimum and maximum floor surface area. The answer to your calculation will fall between the minimum and maximum areas of one of the heating cables - this is the cable for you.
  • U16C 7 Day Programmable Thermostat (must be ordered separately). Has both air and floor sensors. .
  • Insulation
    To prevent downward heat loss, we recommend that EHC cables are installed onto F-Board insulation. F-Board is a low-profile insulated tile backer board.
  • See each product
See product for Accessories, Boxes and Grommets

Technical:

See each product

Order Code
Description
Price (ex VAT)
Price (inc VAT)
Quantity
product photo

BN EHC012

Warm Tile Kit 120w 0.7 - 1.0 Sq Mtr

EA

£35.00

EA

£42.00

product photo

BN EHC020

Warm Tile Kit 200w 1.1 - 1.5 Sq Mtr

EA

£37.25

EA

£44.70

product photo

BN EHC025

Warm Tile Kit 250w 1.6 - 2.0 Sq Mtr

EA

£41.75

EA

£50.10

product photo

BN EHC032

Warm Tile Kit 320w 2.1 - 2.5 Sq Mtr

EA

£52.15

EA

£62.58

product photo

BN EHC040

Warm Tile Kit 400w 2.6 - 2.9 Sq Mtr

EA

£54.40

EA

£65.28

product photo

BN EHC045

Warm Tile Kit 450w 3.0 - 3.3 Sq Mtr

EA

£64.40

EA

£77.28

product photo

BN EHC052

Warm Tile Kit 520w 3.4 - 3.8 Sq Mtr

EA

£66.25

EA

£79.50

product photo

BN EHC060

Warm Tile Kit 600w 3.9 - 4.5 Sq Mtr

EA

£83.50

EA

£100.20

product photo

BN EHC075

Warm Tile Kit 750w 4.6 - 6.0 Sq Mtr

EA

£92.25

EA

£110.70

product photo

BN EHC095

Warm Tile Kit 950w 6.1 - 7.5 Sq Mtr

EA

£109.00

EA

£130.80

product photo

BN EHC110

Warm Tile Kit 1100w 7.6 - 8.5 Sq Mtr

EA

£133.00

EA

£159.60

product photo

BN EHC130

Warm Tile Kit 1300w 8.6 - 10.0 Sq Mtr

EA

£149.00

EA

£178.80

product photo

BN EHC170

Warm Tile Kit 1700w 10.1 - 13.0 Sq Mtr

EA

£195.00

EA

£234.00

product photo

BN EHC200

Warm Tile Kit 2000w 13.1 - 15.5 Sq Mtr

EA

£262.50

EA

£315.00

product photo

BN FB6

6mm F Board Tile Backer Board 1200x600mm per sheet

EA

£11.75

EA

£14.10

product photo

BN FB10

10mm F Board Tile Backer Board 1200x600mm per sheet

EA

£12.70

EA

£15.24

product photo

BN U16C

7 Day Programmable Floor Sensor and Ambient Thermostat

EA

£59.00

EA

£70.80

product photo

BN T16CS

7 Day Programmable Touch Screen Thermostat - Silver

EA

£84.30

EA

£101.16

product photo

BN T16CW

7 Day Programmable Touch Screen Thermostat - White

EA

£79.00

EA

£94.80

product photo

BN T16R

Optional IP65 Remote Sensor for T16 Thermostats

EA

£11.75

EA

£14.10

product photo

BN A16C

Manual Warm Mat Controller/Thermostat

EA

£53.85

EA

£64.62
